Bugs in NXP Kinetis Ethernet Driver

The SDK^[1] drivers provided by NXP for use on the Kinetis K64 platform are extensive, well-tested and … not perfect. This article shows three bugs found in the ethernet driver. Note that none of this is original content; I merely put it together here for my future reference.

Forgetting to check for zero-length buffers

I have only seen this bug happen once in two years and have not found a way to reproduce it at will. So the analysis below may or may not be correct.

The symptom was that the firmware froze upon triggering the assertion in lwip/port/enet_ethernetif_kinetis.c:

“Buffer returned by ENET_GetRxFrame() doesn’t match any RX buffer descriptor”

After some Googling I found this forum thread, which suggests, in a roundabout way, that there is a missing check in fsl_enet.c. We have to add following to ENET_GetRxFrame():

if (curBuffDescrip->length == 0U)
{
    /* Set LAST bit manually to let following drop error frame
       operation drop this abnormal BD.
    */
    curBuffDescrip->control |= ENET_BUFFDESCRIPTOR_RX_LAST_MASK;
    result = kStatus_ENET_RxFrameError;
    break;
}

The NXP engineer on the forum explains: “I didn’t use this logic because I never meet this corner case and consider it a redundant operation.” I was curious if this “corner case” every happens, so I added a breakpoint, which got triggered after about two days of constant testing.

ChatGPT seems to think this check is necessary (but then again, I seem to be able to convince it of just about anything I do or do not believe in):

If you omit the check and DMA ever delivers a BD with length == 0: Your code will think it’s still in the middle of assembling a frame. It will not see the LAST bit yet, so it will happily advance to the next BD. That means the logic walks into an inconsistent state: rxBuffer may point to nothing, your rxFrame bookkeeping goes out of sync, and later you’ll crash on a buffer underrun, invalid pointer, or corrupted frame queue.

It remains to be seen if this check was behind my original crash, and if the body of the if statement is appropriate to handle the condition of unexpected zero-length buffer descriptor.

Credit: User pjanco first reported the error, while AbnerWang posted the solution. [source]

Incorrect memory deallocation

In fsl_enet.c, the function ENET_GetRxFrame() tries to deallocate the pointer of the receive buffer:

while (index-- != 0U)
{
    handle->rxBuffFree(base, &rxFrame->rxBuffArray[index].buffer,
        handle->userData, ringId);
}

First need to unpack some definitions to understand what the above means.

1. If we dig into the rxBuffFree() function, we discover it in the file lwip/port/enet_ethernetif_kinetis.c. The buffer to be deallocated is passed as a pointer void * buffer, and freed

   int idx = ((rx_buffer_t *)buffer) - ethernetif->RxDataBuff;
   ethernetif->RxPbufs[idx].buffer_used = false;



2. Next, what are rxFrame and rxBuffArray? The first one is of type enet_rx_frame_struct_t, which is defined in fsl_enet.h:

   typedef struct _enet_rx_frame_struct
   {
       enet_buffer_struct_t *rxBuffArray;
       ...
   } enet_rx_frame_struct_t;



   This allows us to see what is the type of rxBuffArray:

   typedef struct _enet_buffer_struct
   {
       void *buffer;
       uint16_t length;
   } enet_buffer_struct_t;



3. Finally, what is ethernetif->RxDataBuff? We find it declared in lwip/port/enet_ethernetif_kinetis.c as the static array in the function ethernetif0_init():

   SDK_ALIGN(static rx_buffer_t rxDataBuff_0[ENET_RXBUFF_NUM],
       FSL_ENET_BUFF_ALIGNMENT);
   ethernetif_0.RxDataBuff = &(rxDataBuff_0[0]);



   More precisely, RxDataBuff is a pointer to the first element of this array. This pointer therefore has the type rx_buffer_t*.

   That type itself is declared at the top of the same file as an aligned version of a uint8_t buffer:

   typedef uint8_t rx_buffer_t[SDK_SIZEALIGN(ENET_RXBUFF_SIZE,
       FSL_ENET_BUFF_ALIGNMENT)];



Now we can take a step back and think whether the idx calculation would be best done with the buffer itself, or a pointer to it. The calculation subtracts the following:

• rxFrame->rxBuffArray[index].buffer, of type void*, is a pointer to the memory location that stores the ethernet frame.

• ethernetif->RxDataBuff, of type rx_buffer_t*

The corrected code should pass the buffer pointer stored in .buffer, not the address of the .buffer field (omit the &):

handle->rxBuffFree(base, rxFrame->rxBuffArray[index].buffer,
    handle->userData, ringId);

Credit: This bug was found by KC on 7/31/2024.

Buffers not zero-initialized

Another bug in ethernetif0_init() in enet_ethernetif_kinetis.c: the ethernet buffer descriptor structs are declared static:

AT_NONCACHEABLE_SECTION_ALIGN(
    static enet_rx_bd_struct_t rxBuffDescrip_0[ENET_RXBD_NUM],
    FSL_ENET_BUFF_ALIGNMENT);
AT_NONCACHEABLE_SECTION_ALIGN(
    static enet_tx_bd_struct_t txBuffDescrip_0[ENET_TXBD_NUM],
    FSL_ENET_BUFF_ALIGNMENT);

The assumption is that since they are declared static, the descriptors will be zero-initialized at system startup. However, the macro AT_NONCACHEABLE_SECTION_ALIGN potentially places these descriptor in a special section that can bypass the zero-initialization, depending on the startup code and linker script.

In that case, we need to manually zero out these buffers. I put the following at the top of ethernetif_enet_init() in enet_ethernetif_kinetis.c:

// Buffer descriptors must be initialized to zero
memset(&ethernetif->RxBuffDescrip[0], 0x00, ENET_RXBD_NUM*sizeof(ethernetif->RxBuffDescrip[0]));
memset(&ethernetif->TxBuffDescrip[0], 0x00, ENET_TXBD_NUM*sizeof(ethernetif->TxBuffDescrip[0]));

Credit: This bug was also found by KC.
