STM32MP135 Without U-Boot (TF-A Falcon Mode)

This is Part 3 in the series: Linux on STM32MP135. See other articles.

In this article, we use Arm Trusted Firmware (TF-A) to load the Linux kernel directly, without using U-Boot.^[1] I have seen the idea of omitting the Secondary Program Loader (SPL) referred to as “falcon mode”, since it makes the boot process (slightly) faster. However, I am primarily interested in it as a way of reducing overall complexity of the software stack.

In this article, we will implement this in two ways. First, we modify the files as needed manually. At the end of the article, we provide an alternative method: directly integrate the changes into Buildroot.

Prerequisites

To get started, make sure to have built the default configuration as per the first article of this series. Very briefly, this entails cloning the official Buildroot repository, selecting a defconfig, and compiling:

$ git clone https://gitlab.com/buildroot.org/buildroot.git --depth=1
$ cd buildroot
$ make stm32mp135f_dk_defconfig
$ make menuconfig # add the STM32MP_USB_PROGRAMMER=1 flag to TF-A build
$ make

It is also recommended to learn how to flash the SD card without removing it via a USB connection, as explained in the second article.

Tutorial

The procedure is pretty simple. All we need to do is to modify some files, adjust some build parameters, recompile, and the new SD card image is ready to test.

1. Before making any modifications, make a backup of the file containing U-Boot.

   $ cd output/images
   $ cp fip.bin fip_uboot.bin



   Double check that the above fip.bin was built using the additional ATF build variable STM32MP_USB_PROGRAMMER=1, otherwise USB flashing will not work!

   Open flash.tsv, and update the fip.bin to fip_uboot.bin there as well.

   (Despite removing U-Boot from the boot process, we are still going to use it to flash the SD card image via USB using the STM32CubeProg.)

2. Two TF-A files need to be modified, so navigate to the TF-A build directory:

   $ cd ../build/arm-trusted-firmware-lts-v2.10.5



   Since the kernel is much bigger than U-Boot, it takes longer to load. We need to adjust the SD card reading timeout. In drivers/st/mmc/stm32_sdmmc2.c, find the line

   timeout = timeout_init_us(TIMEOUT_US_1_S);



   and replace it with

   timeout = timeout_init_us(TIMEOUT_US_1_S * 5);



   Next, we would like to load the kernel deep enough into the memory space so that relocation of the compressed image is not necessary. In file plat/st/stm32mp1/stm32mp1_def.h, find the line

   #define STM32MP_BL33_BASE              STM32MP_DDR_BASE



   and replace it with

   #define STM32MP_BL33_BASE              (STM32MP_DDR_BASE + U(0x2008000))



   Finally, in order to allow loading such a big BL33 as the kernel image, we adjust the max size. In the same file, find the line

   #define STM32MP_BL33_MAX_SIZE          U(0x400000)



   and replace it with

   #define STM32MP_BL33_MAX_SIZE          U(0x3FF8000)



3. Next, we need to modify a couple build parameters. Open the make menuconfig and navigate to Bootloaders ---> ARM Trusted Firmware (ATF).

   • Under BL33, change from U-Boot to None.

   • Under Additional ATF build variables, make sure that U-Boot is not present and add the following key-value pairs:

     BL33=$(BINARIES_DIR)/zImage BL33_CFG=$(BINARIES_DIR)/stm32mp135f-dk.dtb



   Select “Ok” and “Esc” out of the menus, making sure to save the new configuration.

   Next, open the file board/stmicroelectronics/common/stm32mp1xx/genimage.cfg.template and increase the size of the fip partition, for example:

   partition fip {
   	image = "fip.bin"
   	size = 8M
   }



   Finally, since U-Boot will no longer be around to pass the Linux command line arguments, we can instead pass them through the device tree source. Open the file output/build/linux-6.12.22/arch/arm/boot/dts/st/stm32mp135f-dk.dts (you may have a different Linux version, just modify the path as appropriate) and add the bootargs into the chosen section, as follows:

   chosen {
   	stdout-path = "serial0:115200n8";
   	bootargs = "root=/dev/mmcblk0p4 rootwait";
   };



4. Now we can rebuild the TF-A, the device tree blob, and regenerate the SD card image. Thanks to the magic of Buildroot, all it takes is:

   $ make linux-rebuild
   $ make arm-trusted-firmware-rebuild
   $ make



   Keep in mind that rebuilding TF-A is needed any time the Linux kernel or DTS or TF-A sources change, since the kernel gets packaged into the fip by the TF-A build process. In this case, the first make rebuilds the DTB, the second packages it in the fip, and the third makes sure it gets into the SD card.

5. Set DIP switch to serial boot (press in the upper all of all rockers) and flash to SD card:

   $ sudo ~/cube/bin/STM32_Programmer_CLI -c port=usb1 -w output/images/flash.tsv



   Then reconfigure the DIP switches for SD card boot (press the bottom side of the second rocker switch from the left), and press the black reboot button.

If you watch the serial monitor carefully, you will notice that we transition from TF-A directly to OP-TEE and Linux. Success! No U-Boot in the boot process:

NOTICE:  Model: STMicroelectronics STM32MP135F-DK Discovery Board
NOTICE:  Board: MB1635 Var1.0 Rev.E-02
NOTICE:  BL2: v2.10.5(release):lts-v2.10.5
NOTICE:  BL2: Built : 20:58:52, Sep 10 2025
NOTICE:  BL2: Booting BL32
I/TC: Early console on UART#4
I/TC:
I/TC: Embedded DTB found
I/TC: OP-TEE version: Unknown_4.3 (gcc version 14.3.0 (Buildroot 2025.08-rc3-87-gbbb0164de0)) #1 Thu Sep  4 03:06:46 UTC 2025 arm
...
(more OP-TEE messages here)
...
[    0.000000] Booting Linux on physical CPU 0x0
[    0.000000] Linux version 6.12.22 (jk@Lutien) (arm-buildroot-linux-gnueabihf-gcc.br_real (Buildroot 2025.08-rc3-87-gbbb0164de0) 14.3.0, GNU ld (GNU Binutils) 2.43.1) #1 SMP PREEMPT Wed Sep  3 20:23:46 PDT 2025
[    0.000000] CPU: ARMv7 Processor [410fc075] revision 5 (ARMv7), cr=10c5387d

Buildroot integration

Instead of following the above instructions, we can automate the build process by integrating it into Buildroot. To this end, I provide the GitHub repository stm32mp135_simple that can be used as follows.

Clone the Buildroot repository. To make the procedure reproducible, let’s start from a fixed commit (latest at the time of this writing):

$ git clone https://gitlab.com/buildroot.org/buildroot.git
$ cd buildroot
$ git checkout 5b6b80bfc5237ab4f4e35c081fdac1376efdd396

Obtain this repository with the patches we need. Copy the defconfig and the board-specific files into the Buildroot tree.

$ git clone git@github.com:js216/stm32mp135_simple.git
$ cd buildroot # NOT stm32mp135_simple
$ git apply ../stm32mp135_simple/patches/add_falcon.patch
$ git apply ../stm32mp135_simple/patches/increase_fip.patch
$ cp ../configs/stm32mp135_simple/stm32mp135f_dk_falcon_defconfig configs
$ cp -r ../board/stm32mp135_simple/stm32mp135f-dk-falcon board/stmicroelectronics

Build as usual, but using the new defconfig:

$ make stm32mp135f_dk_falcon_defconfig
$ make

Flash to the SD card and boot into the new system. You should reach the login prompt exactly as in the default configuration—but without involving U-Boot

Discussion

To port the “default” STM32MP135 setup^[2] to a new board design, one is expected to be comfortable writing and modifying the drivers and device tree sources that work with

• Arm Trusted Firmware (Primary Program Loader)
• OP-TEE (Trusted Execution Environment)
• U-Boot (Secondary Program Loader)
• Linux kernel
• Buildroot, or, worse, Yocto

That is a tall order for a new embedded developer trying to get started integrating Linux in their products. To make things worse, there is at present almost no literature to be found suggesting that a simpler, saner method exists. Certainly the chip vendors themselves do not encourage it.^[3]

With this article, we have began chipping away at the unnecessary complexity. We have removed U-Boot from the boot chain. (We still use it for copying the SD card image via USB. One thing at a time!) Since our goal is to run Linux, the list above gives us a blueprint for the work that remains to be done: get rid of everything that is not Linux.

The software that you do not run is software you do not have to understand, test, debug, maintain, and be responsible for when it breaks down ten years down the line in some deeply embedded application, perhaps in outer space.

Upstreaming Status

19/12/2024: original Buildroot mailing list submission (1/1)

16/12/2025: response by Arnout Vandecappelle (link)

17/9/2025: amended submission (v2 0/2, 1/2, 2/2)
